Einstar 2

Einstar 2

Still EINSTAR, Even Better

Key Feature:

  • 17 parallel laser lines
  • IR VCSEL
  • Reliable scans of dark and reflective metal surface without spray required
  • Reliable performance in dynamic lighting and complex environments

REQUEST QUOTE

The upgrade you’ve been waiting for

Smarter, lighter, finer Einstar 2 takes everything you loved about the original and levels it up. Say goodbye to tangled cables, messy prep work, and limited mobility. With a hybrid light source, true wireless design, and vivid full-color capture, Einstar 2 delivers studio-quality 3D scans with zero fuss.
From screw-sized objects to entire van interiors, from indoor setups to outdoor explorations, Einstar 2 handles all for creators, hobbyists, and curious minds alike. Serious results. No serious experience required.

  • Quick Links
  • 17 parallel laser lines

    Your go-to solution for high-resolution scanning of fine details in small objects. The dense array of 17 parallel lines enhances efficiency for medium-sized scans, cutting time and effort. Improving performance on reflective and metallic surfaces. High-speed scanning of up to 90 fps.

Get a Call Back

Leave us your details our team will get in touch soon

Videos

Product Gallery

Einstar 2-1

Einstar 2-1

Einstar 2-2

Einstar 2-2

Einstar 2-3

Einstar 2-3

Einstar 2-4

Einstar 2-4

Detailed Specifications

Scan Mode
  • Laser HD
  • IR Rapid
Light Source
  • 17 Blue Laser Parallel Lines
  • IR VCSEL
Resolution
  • 0.05 ~ 10 mm
  • 0.2 ~ 10 mm
Scan Speed
  • 2,500,000 points/s
  • 1,440,000 points/s
Working Distance
  • 100 ~ 600 mm
  • 160 ~ 1400 mm
Max. FOV
  • 490 × 580 mm
  • 1170 × 1385 mm
Alignment Mode
  • Global Marker/Markers
  • Global Marker/Markers/Features/Texture/Hybrid
Minimum Scan Volume
  • 10*10*10 mm
  • 50*50*50 mm
Camera Resolution
  • 3D: 2MP*2
Texture
  • 2.3 MP
Output Formats
  • STL, OBJ, PLY, 3MF, ASC
Laser Class
  • Class 2
Outdoor Scanning Environment
  • Below 110,000 Lux
  • Below 70,000 Lux
Operation Conditions
  • Temperature -10℃ ~ 40℃
Interface & Power Source
  • USB Type-C
    Battery: 5500mA*1
    Support 60W-PD 3.0 Charger
Dimension
  • (H*D*W) ：130 x 37 x 61 mm/ 5.12 x 1.46 x 2.40 in
* Volumetric accuracy refers to the relationship between 3D data accuracy and object size; the accuracy is reduced by 0.1mm per 100cm(standard scan & body scan). The conclusion is obtained by measuring the center of sphere under marker alignment.
