Creality Sermoon X1

Creality Sermoon X1

Industrial, Accurate, Wireless

Key Feature:

  • 34 cross laser lines
  • 7 parallel laser lines
  • 1 blue laser line
  • NIR structured light

REQUEST QUOTE

Industrial Strength. Scan Precise

The Creality Sermoon X1 is an industrial-grade 3D scanner designed for high precision and efficiency, featuring both blue laser and infrared scanning modes. It offers a volumetric accuracy of up to (0.02mm+0.04mm) and can scan both small objects from 5 mm and large objects up to 4 meters

  • Quick Links
  • Industrial Precision: Consistent accuracy you can truist

    0.02mm+0.04mm/m 0.02mm+0.03mm/m(with Scale Bar) It redefines the standard for non-destructive inspection, meeting the rigorous 3D measurement demands of the manufacturing industry.

  • Built-in Photogrammetry & 2×Scale Bars equiped

    The scale bar allows the scanner to automatically correct dimensional accuracy during reconstruction with volumetric accuracy 0.02 mm + 0.03 mm/m , ideal for applications where precision matters, such as engineering, restoration, and inspection, etc.

  • Single-Line Laser, Mastering Deep Holes

    The X1 single laser deep-hole scanning mode easily captures 3D data from hard-to-reach areas such as deep holes, narrow gaps, and recesses. It supports scanning narrow holes with a depth-to-diameter ratio of up to 6:1, delivering more complete 3D data for applications in design, inspection, analysis, and beyond.

  • All-Material Adaptability: Seamlessly handles diverse surfaces.

    34+7+1 Blue Laser+NIR Diverse Operating Modes

Get a Call Back

Leave us your details our team will get in touch soon

Videos

Product Gallery

Creality Sermoon x1 3D Scanner-1

Creality Sermoon x1 3D Scanner-1

Creality Sermoon x1 3D Scanner-2

Creality Sermoon x1 3D Scanner-2

Creality Sermoon x1 3D Scanner-3

Creality Sermoon x1 3D Scanner-3

Creality Sermoon x1 3D Scanner-4

Creality Sermoon x1 3D Scanner-4

Creality Sermoon x1 3D Scanner-5

Creality Sermoon x1 3D Scanner-5

Detailed Specifications

Scanning Mode
  • Deep hole scanning
    Single laser line
  • Detailed Scanning
    7 Parallel laser lines
  • High Speed Scanning
    34 Cross laser lines
  • Marker-free Scanning
    NIR(Binocular structured light)
Accuracy
  • Up to 0.02mm
  • Up to 0.05mm
Volumetric Accuracy
  • 0.02mm+0.04mm/m 0.02mm+0.03mm/m(with Scale Bar)
  • 0.05mm+0.1mm/m
Scanning rate
  • 84,000 measurements/s
  • 756,000 measurements/s
  • 1,734,000 measurements/s
  • 5,000,000 measurements/s
Scanning Speed
  • Up to 90fps
  • Up to 85fps
  • Up to 30fps
3D Resolution
  • 0.05-2mm
  • 0.1-2mm
Photogrammetry
  • Include photogrammetry mode(with 2X Magnetic carbon fiber scale bar)
Min. scan volume
  • 5mm x 5mm x 5mm
  • 150mm x 150mm x 150mm
Single Capture Range
  • 215mm x 167mm@200mm
    325mm x 323mm@300mm
    434mm x 394mm@400mm
    542mm x 463mm@500mm
    650mm x 531mm@600mm
  • 650mm x 531mm at 600mm
    1300mm x 935mm at 1200mm
Working distance
  • 200mm-600mm
  • 150mm-400mm
  • 200mm-600mm
  • 170mm-1200mm
Color Mapping
  • Supported
Alignment mode
  • Marker / Global Marker
  • Marker / Global Marker / Geometry / Texture
Color Supplemental Light
  • 12 White LEDs
Outdoor Scanning
  • Below 100,000 lux
  • Below 50,000 lux
  • Below 100,000 lux
  • Below 30,000 lux
Marker Recognition Enhancement
  • 12 Blue LEDs
Laser Safety
  • Class II (eye safe)
Device Weight
  • 530g
Size
  • 216mm*74mm*51mm
Mechanical Structure
  • Optoelectronic bracket and lens base, CNC integrated molding Total mechanical locking (better stability, longer lifespan)
Calibration board
  • High-precision glass calibration board
Wireless Scanning
  • Supported
PC Configuration
  • indows: Recommended: i7-Gen10 CPU, Nvidia graphics card (8GB VRAM), 32GB RAM, Windows 10/11 (64-bit) Minimum: i7-Gen7 CPU, Nvidia graphics card (6GB VRAM), 16GB RAM, Windows 10/11 (64-bit)
    macOS: Recommend M1/M2/M3/M4 series CPU, with 16GB RAM
Interface Mode
  • USB 3.0 × 1
Imput Power
  • 12V, 3A[2]
Operating temperature
  • -10°C to 40°C
Operating humidity
  • 10-90%RH
* Accuracy is evaluated in laboratory conditions (measurement object is 100mm sphere pair) and actual results may be affected by operating environments such as temperature, vibration, and other factors. *The scanner is designed to operate in conjunction with the Scan Bridge,with an input voltage and current rating of 12V/2A.
