The EinScan Rigil offers three operation modes to unlock max performance and flexibility Standalone Mode: No PC connection required, all scanning and processing tasks are completed directly on the hardware. Wireless PC Mode: Leveraging built-in Wi-Fi 6, enables seamless wireless scanning and allows connection to a powerful computer, optimizing performance for complex tasks and large data volumes. Wired PC Mode: Maintaining availability, maximum scanning speed, and data volume in complex network environments.

2 separate groups of cameras are specifically designed to capture different light sources respectively. Blue laser lines VCSEL infrared

Provides high-quality models with 0.04 + 0.06 mm/m volumetric accuracy and high geometric resolution up to 0.05mm. 19 + 19 crossed laser lines: for high speed scanning, delivers top-tier efficiency and flexibility. 7 parallel laser lines: for fine details, provides consistent results

Two laser scan modes can be switched during the scanning process, and the data can be merged to achieve speed and detail in one scanning project.

VCSEL Infrared-powered scanning solution for high efficiency and wide coverage of medium to large objects. Volumetric accuracy up to 0.1 + 0.3 mm/m Working distance 160 ~ 1500 mm Scanning speed up to 1,600,000 points/s

EinScan Rigil features a special tracking algorithm, which provides marker-free blue laser scanning through a Laser + IR hybrid scan mode currently available in EXScan Rigil software. This enables better efficiency than traditional marker-based laser scanning and better data quality than marker-free IR scanning.
